Description
Low-k dielectric material for laboratory test adopts material with dielectric constant (εr) less than or equal to 1.4. It features high strength and good heat resistance, and can be used as support material in EMC test.
Low-k Dielectric Material for Laboratory Test
Standard
- ISO 10605
- ISO 11452-4
- GJB 151B
- GB/T18655
- GB/T 21437.2
- GB/T 21437.3
- GB/T 9254
Specifications
| Model No. Overview | ||||||
|---|---|---|---|---|---|---|
| Model No. | Standard | Test Projects | Requirement for dielectric constant | Quantity | Dimension(cm)
(L*W*H) |
Note |
| DL 16010080 | GB/T 9254 | radio emission | No requirement | 1 pcs | 160*100*80 | Table 160*100*6cm |
| DL 100255 | GB/T 18655 | Vehicle electronic conducted test | ≤1.4 | 1 pcs | 100*25*5 | Current method, with slotting at 5cm and 75cm. with cable tie |
| DL 50255 | 2 pcs | 50*25*5 | plane, insulation cable bundle | |||
| DL 60305 | 2 pcs | 60*30*5 | Plane | |||
| DL 100255 | ISO 10605 | Static electricity discharge | 1~5 | 1 pcs | 100*25*5 | With magic tape tie and cable tie |
| DL 50255 | 2 pcs | 50*25*5 | ||||
| DL 100255 | ISO 11452-4 | BCI test | ≤1.4 | 1 pcs | 100*25*5 | with slotting at 5cm, 15cm, 45cm and 75cm, with cable tie |
| DL 50255 | 2 pcs | 50*25*5 | Planeplane, insulation cable bundle | |||
| DL 60305 | 2 pcs | 60*30*5 | Plane | |||
| Model No. | Standard | Test Projects | Requirement for dielectric constant | Quantity | Dimension(cm)
(L*W*H) |
Note |
| DL 50305 | GJB 151B | General setup | As low as possible, not specified in standard | 2 pcs | 50*30*5 | Make 5 slottings with 2 cm spacing distance along the long axis to put cable bundle.
Slotting width is 2 cm and the distance from slotting bottom to plan bottom is 5 cm. |
| DL 100305 | 2 pcs | 100*30*5 | ||||
| DL 50255 | GB/T 21437.2 | Vehicle transient immunity test | ≤1.4 | 1 pcs | 50*25*5 | insulation cable bundle |
| DL 60305 | 2 pcs | 60*30*5 | ||||
| DL 100255 | GB/T 21437.3 | Vehicle transient immunity test | ≤1.4 | 1 pcs | 100*25*5 | Plane, insulation cable bundle（1700mm） |
| DL 50255 | 2 pcs | 50*25*5 | ||||
| DL 60305 | 2 pcs | 60*30*5 | ||||
