Programmable DC Power Supply PDG

Model：PDG 50C50S

PDG 50C50S programmable DC power supply is designed according to GJB181A-2003, GJB181B-2012, HB 20326.8-2016 standards.

In Stock
Enquire Now
Share (0)
Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0

Description

PDG 50C50S programmable DC power supply is designed according to GJB181A-2003, GJB181B-2012, HB 20326.8-2016 standards, with A maximum output of 50 V / 50 A with test software and auxiliary measuring equipment (such as: Oscilloscope, spectrum analyzer, distortion tester, etc.) can realize all the tests in HB 20326.8-2016 standard. It can also be used for superimposed AC interference signal test in GJB181 standard. The operation of the instrument is simple and intuitive and the reliability is strong.

Features：

  •  5.7-inch display;
  •  Reliable quality, beautiful appearance, comfortable operation;
  •  The integrated design makes the system more simple, safe and durable;
  •  Ethernet, RJ45 interface, for PC remote control printing test reports.

Standard

  • GJB 181A-2003
  • GJB181B-2012
  • HB 20326.8-2016

Specifications

Technical Parameters：
Maximum Output Voltage 50 V
Maximum
Current Output		 50 A
Ripple Wave
(20 Hz ~ 20M Hz)		 Vpp≤1 %FS ＋ 100 mV
Vrms≤0.3 %FS ＋ 50 mV
Dynamic Response Time（10% ~ 90%load) ≤5ms
General Parameters：
Display Screen 5.7-inch TFT touch screen
Operating Power Supply AC 380 V
Max Power 3000 W
Communication Mode Ethernet LAN、RJ45
External Control Mode D-sub 25p
Failure Detection Failure of the front panel LCD display, and interrupt the instrument work
Operating Status Front panel LED indicators
Grounding Method Flat grounding strap
EUT Supply Voltage Injection φ4 or φ6 mm banana plug cable
Dimension 19-inch/22 U
Weight About 125 kg
Ambient Temperature 15 ℃ ~ 35℃
Relative Humidity 45% ~ 75%
Atmospheric Pressure 86 kPa ~ 106 kPa

Downloads

Adobe PDF

3Programmable DC Power Supply PDG 50C50S Datasheet

Language: English
