Rigol DSA832-TG

Name: Rigol DSA832-TG
SKU: DA832-TG
Price: 706053.00 INR
Availability: InStock

Code: DA832-TG

High quality spectrum analyzer from 9 kHz to 3.2 GHz with Tracking Generator.

Displayed Average Noise Level (DANL) normalized to 1 Hz ranging from -135 dBm to -161 dBm typical
-80 to -98 dBc/Hz @10 kHz offset Phase Noise
Total Amplitude Uncertainty from <1.5 dB to <0.8 dB nominal
100 or 10 Hz Minimum Resolution Bandwidth (RBW) available
Up to 3.2GHz Tracking Generator (DSA832-TG)

Now includes NABL Calibration Certificate.

3 years warranty

~~₹753,123.00~~ ₹706,053.00

In Stock 2-3 Weeks

Description

The Rigol DSA832-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA832-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.

Model-Overview	Max. Bandwidth	EMI/QuasiPeak	Adv. Meas. Kit	Preamplifier	Tracking Gen.
DSA815	1.5 GHz	optional	optional	Stanadard	X
DSA815-TG	1.5 GHz	optional	optional	Stanadard	Stanadard
DSA832E	3.2 GHz	optional	optional	Stanadard	X
DSA832E-TG	3.2 GHz	optional	optional	Stanadard	Stanadard
DSA832	3.2 GHz	optional	optional	Stanadard	X
DSA832-TG	3.2 GHz	optional	optional	Stanadard	Stanadard
DSA875	7.5 GHz	optional	optional	Stanadard	X
DSA875-TG	7.5 GHz	optional	optional	Stanadard	Stanadard

Special Features

Spectrum compare

10 Hz RBW

AM Signal Demodulation

Peak table function

EMI Measurement (option)

Preamplifier

Specifications

Spektrum Analyzer	Rigol DSA832-TG
Display	20,3 cm (8″) TFT-Color-LCD
Resolution	800 × 480 Pixel
Interfaces	USB-Host (for USB stick i.e. to save/load waveforms) USB for a PC connection LAN for network connection GPIB (IEE-488, General Purpose Interface Bus) The GPIB function is only available with the use of the optional available USB GPIB module
Dimensions	362 mm × 179 mm × 128 mm (15.71″ × 8.78″ × 6.26″)
Weight	4.55 kg (10.03 lbs)

The complete list of technical specifications can be found in chapter 5 “Specifications” of the manual. A shorter overview is available in the datasheet.

Function	Rigol DSA832-TG
Channels	1
Frequency Range	9 kHz to 3.2 GHz
Frequency Resolution	1 Hz
Internal Frequency Reference	10 MHz
Span	0 Hz (zero Span) 100 Hz to 3.2 GHz
DANL (Displayed Average Noise level)	9 kHz to 100 kHz 100 KHz to 5 MHz 5 MHz to 3.2 GHz	<-120 dBm (typ.) <-135 dBm, <-138 dBm (typ.) <-140 dBm, <-144 dBm (typ.)
DANL (with Preamplifier) (Displayed Average Noise level)	9 kHz to 100 kHz 100 KHz to 5 MHz 5 MHz to 3.2 GHz	<-152 dBm (typ.) <-152 dBm, <-155 dBm (typ.) <-157 dBm, <-161 dBm (typ.)
Amplitude Range	DANL to +20dBm
Max. Input Voltage	50 V
Sweeptime Range	Span >= 100 Hz zero span	10 ms to 3200 s 20 µs to 3200 s
Resolution Bandwidth (RBW)	10 Hz to 1 MHz (in 1-3-10 sequence)
Video Bandwidth (VBW)	1 Hz to 3 MHz (in 1-3-10 sequence)
Input Impedance	50 Ohm nominal
