The Vehicle Power Supply Circuit Positive

Description

The vehicle power supply circuit positive surge simulator TIS 60T3 is designed according to Toyota TSC0502G, which can be used to evaluate the resistance of the devices to the positive surge voltage that is produced when the battery terminals become disconnected.
It is capable of generating high-frequency pulse (Fig. 15), giant pulse (Fig. 17) and positive pole surge (Fig.19) specified in TSC0502G, featuring easy and intuitive setting design.

Features:

• 5.7” color touch screen;
• Satisfy the test requirement of positive surge test specified inToyotaTSC0502G;
•  Built-in DC switch for spark test;
• Ethernet and RJ45 interface for PC remote control and test report printing;
