Wide-band Current Monitor CM 0103M

Model：CM 0103M

The CM 0103M is used for measuring alternating current and time domain pulse current in the frequency range from 200 Hz to 20 MHz.

In Stock
Enquire Now
Share (0)
Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0

Description

The CM 0103M is used for measuring alternating current and time domain pulse current in the frequency range from 200 Hz to 20 MHz. It features no waveform distortion and physically isolation with current carrier and transmits time harmonics current or pulse current to recording instruments in the form of voltage, which meet the measurement requirement of time harmonics signal with frequency of 20 MHz or below and transient pulse with rise time less than 18 ns. Widely used in tests of EMC conductive sensitivity (immunity).

s21 curve of CM 0103M

Standard

Specifications

Technical Parameters
Sensitivity 0.1 V/A High Frequency 3 dB cut-off 20 MHz
Output Resistance 50 Ω Inner Diameter 40 mm
Max. Peak Current 5,000 A Outer Diameter 116 mm
Max. rms Current 50 A Thickness 40 mm
Rise Time 18 ns Interface Type BNC type
Current Time Product 0.2 A·s Operating Temperature 0 ℃ ~ 65 ℃
Low Frequency 3 dB cut-off 200 Hz Weight 1 kg

Downloads

Adobe PDF

Wide-band Current Monitor CM 0103M Datasheet
